| Product Specification | |
|---|---|
| Working Table | 1300*2500*200mm |
| spindle | 9.KW Air Cooling with Liner ATC 8 tools |
| Control System | NK260 Control Systems |
| Spindle RPM | 18000rmp/min ER32 |
| Working Table | Vacuum & T Slot |
| Driving System | Leadshine 850W Servo Motor and Driver |
| XY Axis Structure | Helical Rack and Pinion and Japan Shimpo Reducer |
| Z Axis Structure | Original Taiwan TBI ball screw |
| XYZ Axis Square rails | Original Taiwan HIWIN brand square rails |
| Inveter | Fuling Brand 11.KW |
| Electric Parts | France Schneider / Omron Japan |
| Oil Lubrication | Hand Control with Aluminum Oil Pipe |
| Machine Max. Travel Speed | 30m/min |
| Machine Max. Working Speed | 20m/min |
| Machine Voltage | 3PH 380V 50/60HZ |
| Machine Size | 4000*2280*2000mm |
| Machine Weight | 1800KG |
